Amplifier Section
Power Output
All Channels 160 W/Ch (6, 1 kHz, 1% THD, 1 Channel Driven, IEC)
175W/Ch (6, 1 kHz, 1 Channel Driven, JEITA)
Dynamic Power
240 W (3, Front)
210 W (4, Front)
120 W (8, Front)
THD+N (Total Harmonic Distortion + Noise) 0.08% (20 Hz–20 kHz, Half Power)
Damping Factor 60 (Front, 1 kHz, 8)
Input Sensitivity and Impedance
200 mV/47 k (Line)
2.5 mV/47 k (Phono MM)
Rated RCA Output Level and Impedance
200 mV/2.2 k (Line Out)
Maximum RCA Output Level and Impedance
2.0 V/2.2 k (Line Out)
Phono Overload 70 mV (MM, 1 kHz, 0.5%)
Frequency Response 5 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
Tone Control
10 dB, 20 Hz (Bass)
10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio 106 dB (Line, IHF-A)
80 dB (Phono MM, IHF-A)
Speaker Impedance 4 – 16 or 6 – 16
Video Section
Input Sensitivity/Output Level and Impedance
Video 1.0 Vp–p/75 (Component Y) 0.7 Vp–p/75 (Component PB/CB, PR/CR)
1.0 Vp–p/75 (Composite)
Component Video Frequency Response
5 Hz–100 MHz/+0 dB, -3 dB
Tuner Section
Tuning Frequency Range
FM 87.5 MHz–108 MHz
AM 522 kHz–1,611 kHz
530 kHz–1,710 kHz
FM/AM Preset Memory 40 Stations
General
Power Supply AC 220−240 V, 50/60 Hz
(Taiwan Model: AC 120 V, 60 Hz)
Power Consumption 630 W
No-Sound Power Consumption
75 W
Standby Power Consumption
0.15 W
Dimensions (W x H x D) 435 x 173.5 x 329 mm
Weight 10.5 kg
CARTON
Dimensions (W x H x D) 570 x 297 x 423 mm
Weight 13.0 kg
Supplied Accessories
• Indoor FM antenna
• Antenna isolator*
• AM loop antenna
• Color labels for speaker cables
• Speaker setup microphone
• Instruction manual
• Remote controller
• AA (R6) batteries** x 2
